National Lab laboratory freezer Thorbi Genius TGF115S
The Thorbi Genius TGF115S is a laboratory freezer that offers particularly precise temperature control and is predestined for a wide range of applications in research, medicine and industry thanks to its robust design. Comparisons such as [National Lab Laboratory Freezer Thorbi Compact 40] underline that this freezer is always used when sensitive substances need to be safely preserved at constant sub-zero temperatures thanks to its reliable cooling system and user-friendly functions.

Detailed description

The appliance is designed for temperatures between -10 °C and -30 °C and can be finely adjusted using a digital controller with touchscreen. This allows laboratory staff to vary the temperature according to individual specifications and, thanks to alarm functions, they receive immediate notification of potential faults or operating errors. A self-closing full door with handle and lock, supported by a three-chamber door seal, secures the interior. The innovative door sensor system also stops the air circulation system during opening to save energy and keep temperature losses to a minimum.

Other features such as automatic (hot gas) defrosting and the powerful air circulation system with epoxy-coated evaporator make the daily work in many laboratories easier, as cleaning cycles are reduced and the appliance returns to operating temperature more quickly. At the same time, the heated door frame construction prevents the door from freezing, so that closing and reopening always works perfectly.

The outer and inner surfaces are made of white plastic-coated, galvanized sheet steel. The rounded interior corners support easy cleaning – an often essential requirement for pharmaceutical and medical technology. The integrated LED interior lighting provides a clear view of samples and materials so that they can be accessed efficiently and safely. Similar equipped products such as [National Lab laboratory freezer Thorbi Genius TGF215S] show that National Lab generally relies on a well-coordinated overall concept in which durability, ease of service and performance go hand in hand.

Important features and technical data

– Temperature range: -10 °C to -30 °C
– Climate class: 4 (30 °C and 55 % relative humidity)
– Usable capacity: 129 liters with 3 height-adjustable shelves (max. 25 kg load capacity each)
– External dimensions (W × D × H): 600 × 637 × 823 mm
– Internal dimensions (W × D × H): 505 × 456 × 452 mm
– Weight: 62 kg
– Insulation: High-pressure polyurethane with high density (ODP = 0)
– Automatic defrosting: Hot gas defrosting
– Door: solid door with lock, three-chamber door seal, heated door frame

In addition, this freezer works with an environmentally friendly refrigerant (R290, also ODP = 0), which is characterized by its high efficiency and low environmental impact. The appliance requires a 230 V connection for the power supply.

Thanks to all these technical strengths, the freezer meets the most important requirements in professional workflows. It prevents temperature fluctuations that could jeopardize important samples and is easy to maintain.

Certifications and standards

National Lab attaches great importance to compliance with current standards and test procedures. In practice, this means that every cooling system is tested for integrity with helium and meets strict safety standards. A high level of operational safety is guaranteed thanks to solid device production and extensive alarm technology, including visual and acoustic warning signals.

Examples of applications

– Research facilities: For long-term storage of temperature-sensitive reagents, enzymes or reference samples that remain stable at -20 °C.
– Clinical laboratories: For storing vaccines, blood plasma or diagnostic materials that require a stable freezer area.
– Pharmaceutical industry: Sample storage, stability tests and quality assurance at constant temperatures.
– Food technology companies: For storing rare raw materials or additives that need to be stored particularly gently at low temperatures.

FAQs

How often should the appliance be defrosted

?

Manual defrosting is not necessary as the appliance has an automatic hot gas defrosting system. This ensures stable operation without major interruptions.

Which samples and materials can be optimally stored inside?

Everything that requires a temperature range of around -10 °C to -30 °C, such as sensitive biological samples, pharmaceutical substances or enzymes. Pay attention to the applicable regulations for critical materials.

Is calibration required at regular intervals?

Calibration may be advisable depending on the laboratory guidelines. Due to the digital controller and the accuracy of 0.1 °C, the effort is low.

What safety functions are integrated?

In addition to visual and audible alarms in the event of malfunctions and open doors, the lock, door frame heater and door sensor ensure reliable protection of the samples.

Which steps simplify cleaning

The interior has rounded corners and smooth surfaces, allowing deposits to be removed quickly. The sturdy sheet steel with plastic coating also makes disinfection and cleaning easier.

Conclusion

With its sophisticated cooling system, fine temperature control and robust design, this laboratory freezer is ideal for demanding applications. The excellent insulation, energy-saving LED lighting and convenient door technology contribute to the reliable storage of highly sensitive materials. The easy handling not only offers safety and protection against breakdowns, but also a more efficient workflow in the laboratory and production. Anyone who values precision, durability and optimized storage will find a future-proof solution for a wide range of deep-freezing tasks here.

.
