Beschreibung
BINDER drying and heating oven ED056
The BINDER ED056 drying and heating oven is a versatile unit used in various laboratory environments, including scientific and medical research facilities. This drying oven is ideal for the cultivation of microorganisms, bacterial and animal cultures as well as for numerous incubation and development processes. With the ED056 you can observe the behavior of cells and their growth, which helps you to draw well-founded conclusions regarding your research. Similar to the BINDER BF56 incubator, the ED056 offers precise temperature control and reliable performance.
Technical data and features
The BINDER ED056 drying and heating chamber is characterized by a range of technical data and features that make it an indispensable tool in laboratories:
- Oven type:Drying oven
- Max. load:11 – 50 kg
- Internal volume: 57 liters
- Maximum temperature:+300 °C
- Externaldimensions: 560 mm (width) x 625 mm (height) x 565 mm (depth)
- Internaldimensions: 360 mm (width) x 420 mm (height) x 380 mm (depth)
- Weight (empty):39 kg
- Rated voltage:230V (50/60 Hz) or 120V (60 Hz)
- Energy consumption at 150°C:180 Wh/h
- Rated power: 1.05 kW
- Appliance fuse:6.3 A (230V) or 12.5 A (120V)
- Temperature range:15 °C above room temperature up to 300 °C
- Spatial temperature deviation at 150 °C:±2.5 K
- Temporal temperature deviation at 150 °C: ±0.4 K
- Heating time to 150 °C: 45 minutes
- Recovery time after 30 s door opening at 150 °C: 25 minutes
Versatile application possibilities
The ED056 is particularly useful in laboratories in biology, chemistry, pharmacy, medicine and the food industry. It enables the precise regulation of temperature, humidity and other conditions such as carbon dioxide and oxygen levels to create and maintain a specific microclimate. This is particularly important for the cultivation and growth of cells and microorganisms. The BINDER FD056 drying and heating oven with air circulation offers similar functions, but with forced air circulation for an even more even temperature distribution.
Certifications and standards
The BINDER ED056 drying and heating oven meets all relevant safety and quality standards required in laboratory environments. This includes CE markings and other industry-specific certifications that guarantee the safety and reliability of the appliance.
Application examples
- Cultivation of microorganisms:Ideal for growing and observing bacterial and fungal cultures.
- Cell growth:Supports research into cell behavior and growth, which is of great importance in medical and biological research.
- Incubation and development processes:Perfect for carrying out hatching processes in animal research.
- Material testing:Can be used for drying and curing materials in the chemical and pharmaceutical industries.
FAQs
How do I clean the BINDER ED056 drying and heating oven?
- The interior of the ED056 is made of stainless steel and is therefore easy to clean. Use mild detergents and a soft cloth to clean the surfaces.
Can I use the ED056 for drying sensitive samples?
- Yes, the ED056 offers precise temperature control and even temperature distribution, making it ideal for drying sensitive samples.
What accessories are available for the ED056?
- There are a variety of optional accessories, including additional drawers and shelves, which can be replaced or added as required.
Conclusion
The BINDER ED056 drying and heating oven is a versatile and reliable unit that can be used in a variety of laboratory environments. With its precise temperature control, robust construction and wide range of applications, it is an excellent choice for researchers and laboratory technicians. Similar products such as the BINDER FED056 drying and heating oven with convection offer additional options for specific requirements.
| Load max.: | 11 – 50 kg |
| Width outside (incubators,…): | 560 mm |
| Width inside (incubators,…): | 360 mm |
| Maximum temperature (heat): | + 300 °C |
| Height outside (incubators,…): | 625 mm |
| Height inside (incubators,…): | 420 mm |
| Interior volume: | 51 – 100 l |
| Cabinet type: | heating oven |
| Depth outside (incubators,…): | 565 mm |
| Depth inside (incubators,…): | 380 mm |
| Shipping weight: | 59,00 kg |
| Item weight: | 59,00 kg |
| BINDER Drying and heating chambers with natural convection |
ED056-230V | ED056UL-120V |
| Option model | Standard | Standard |
| Measures – Outer dimensions | ||
| Width net (mm) | 560 | 560 |
| Height net (mm) | 625 | 625 |
| Depth net (mm) | 565 | 565 |
| Wall clearance back (mm) | 160 | 160 |
| Wall clearance sidewise (mm) | 100 | 100 |
| Unit doors (Stück) | 1 | 1 |
| Measures – Internal Dimensions | ||
| Width (mm) | 360 | 360 |
| Height (mm) | 420 | 420 |
| Depth (mm) | 380 | 380 |
| Interior volume (l) | 57 | 57 |
| max. Load per rack (kg) | 15 | 15 |
| Net weight of the unit (empty) (kg) | 39 | 39 |
| Electrical data | ||
| Rated Voltage (V) | 230 | 120 |
| Power frequency (Hz) | 50 / 60 | 60 |
| Energy consumption at 150 °C (Wh/h) | 180 | 180 |
| Nominal power (kW) | 1.05 | 1.05 |
| Unit fuse (A) | 6.3 | 12.5 |
| Phase (Nominal voltage) | 1~ | 1~ |
| Performance Data Temperature | ||
| Temperature range 15 °C above ambient temperature to (°C) | 300 | 300 |
| Temperature uniformity at 150 °C (+K) | 2.5 | 2.5 |
| Temperature fluctuation at 150 °C (± K) | 0.4 | 0.4 |
| Heating-up time to 150 °C (min) | 45 | 45 |
| Recovery time after 30 seconds door open at 150 °C (min) | 25 | 25 |
